Home /Products/Laptop Ultrasound Machine/Swine Ultrasound Scanner Diagnostic System Portable Veterinary Ultrasound Scanner

Swine Ultrasound Scanner Diagnostic System Portable Veterinary Ultrasound Scanner

2.0 Sets
MOQ
Swine Ultrasound Scanner Diagnostic System Portable Veterinary Ultrasound Scanner
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: Siho-N50(VET)
Power Source: Electric
Warranty: 1 Year
After-sale Service: Online Technical Support
Material: Metal, Plastic
Shelf Life: 1years
Quality Certification: Ce, CE
Instrument Classification: Class II
Safety Standard: None
Product Name: Portable B/w Ultrasonic
Battery: Removable Lithium Battery /5200 MAh
Type: Medical Ultrasound Instruments
Display: 15 Inch LED Screen
Gain Range: 0-135db
Grey Scale: Level 256
Dynamic Range: 0-135db
Maximum Display Depth: 300mm
Used For: Pigs, Sheep, Cats, Dogs, Cattle, Camels, Etc
Basic Infomation
Certification: ce, CE
Model Number: Siho-N50(VET)
Payment & Shipping Terms
Packaging Details: carton Size:50*50*23cm Weight:4.7KG
Supply Ability: 400 Piece/Pieces per Month
Product Description
Product Description
Product name
Portable B/w Ultrasonic
Display
15 inch
Display mode
B,B+B,4b,B+m,m
language
English
Products Description
Full-digital Laptop Ultrasound Scanner
Flexible and convenient operating system
A type of high array, high definition, multi-function full-digital laptop ultrasonic diagnostic apparatus.
Light and portable, more clearer,delicate and smooth image, convenient to operate, and powerful electrical power ability supports
the machine for consultation in various environment of cities, towns, outdoor.
A variety of charging to ensure the examination consultation under different environments.
Probes: convex probe,trans-vaginal probe, trans-rectal probe, high frequency linear probe, visual artificial abortion probe
Supernormal battery life 4 hours
15 inch LED shows the images with more flexible ways.
USB port: storable and readable
Technical parameter
1. Display: 15 inch LED screen;
2. Probe Interface：Dual probe interface, with automatic identification function
3. Battery Capacity :removable lithium battery /5200 mAh
4. Display mode: B, B + B, 4b, B + m, m;
5. Four encoders, knob design, quick and convenient operation
6. Simple operation interface, easy to understand, ready to use
7. Movie playback: 256 frames, can be played back frame by frame and pause playback, pause playback can be used for image preservation and measurement
8. Language：Chinese/English
9. Electron focusing: four stage electron focusing;
10. There were more than 18 body position markers;
11. Frequency conversion: All probes support five-stage frequency conversion;
12. Image mirror: upper and lower mirror, left and right mirror, black and white flip;
13. Measurement: Professional software measurement package;
14. Character display: date, clock, name, gender, age, doctor, hospital, comment (full-screen character editing);
15. Gain range: 0-135db;
16. Interface: video interface, two USB interface, DICOM interface, VGA interface, power interface
17. Permanent storage: 16G built-in storage, can also be connected to external U disk storage
18. Grey scale: level 256
19. Dynamic range: 0-135db;
20. With the function of puncture guidance, puncture line position can be adjusted
21. With the function of rock positioning and dynamic target tracking
22. Front process: variable aperture, dynamic trace change, dynamic digital filtering, etc
23. After the process: 8 kinds of γ correction, line correlation, 16 level frame correlation, point and line correlation, linear
interpolation, digital spatio-temporal filtering, digital edge enhancement, 8 kinds of false color processing, etc
24. Blind area: ≤4
25. Maximum display depth :300mm
26. Geometric accuracy: transverse ≤5%, longitudinal ≤5%
27. Resolution: lateral ≤2mm, axial ≤1mm
28. Display magnification: 16 display modes; Lesion diagnosis is more accurate.
Enhanced depth display.
29. Host size: 360mm(L)*355mm(W)*65mm(H)
Packing & Delivery
1. All of our equipment will be packed into cartons for small size and wooden cases for the big size.
2. We will pack the different items into one package for saving space if the order qty is more.
3. We will load the package in our factory for safety problem if the order qty is full container.
Company Profile
Henan Siho-Health Medical Equipment Co., Ltd Is a professional supplier of rehabilitation and therapy medical equipment with more than 10 years experience. We have our professional team who has 20 years experience for international trading and medical equipment supplying. We will assure you our professional and timely service to all of our customers. Our company members are united by a common mission: To make Siho group the most trusted medical hospital equipment supplier. We have been wholeheartedly providing holistic solution, special solution and single device and device combination for the rehabilitation center and physiotherapy center. Our clients included Hospitals,laboratories, clinics, physicians Office practices, portable X-ray units Distributors, healthcare workers etc. We are the first choice of equipment for hospitals and clinics! After-sale service is guaranteed by long-term warranties, superior distribution network, and excellent technical support. We are actively exploring close cooperation with the Chinese Society of Rehabilitation Medicine, the American Society of Rehabilitation Medicine, the Taiwan Society of Rehabilitation Medicine and other authoritative organizations, as well as the Rehabilitation Medicine Association in the city where the hospital is located. We will actively cooperate with partners in the areas of rehabilitation medicine expert reserve, technical research, and rehabilitation medical staff training and training.
FAQ
1. who are we?
We are based in Henan, China, sell to North America(30.00%),South America(20.00%),Southeast Asia(10.00%),Western Europe(10.00%),Eastern Europe(10.00%),Africa(5.00%),Eastern Asia(5.00%),Mid East(5.00%),Oceania(5.00%). There are total about 5-10 people in our office.

2. how can we guarantee quality?
Always final Inspection before shipment;

3.what can you buy from us?
Emergency & Clinics Apparatuses, Rehabilitation treatment equipment, Dental Materials, Hospital furniture

4. why should you buy from us not from other suppliers?
We are professional supplier of different medical equipment. We focus our resources on providing safe and reliable medical consumable products to global customers.

5. what services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FCA, DDP；
Accepted Payment Type: T/T,L/C, MoneyGram, PayPal, Western Union;
